Monitor stand and monitor wall mount, center of display 115 cm

column silver anodized, fixed height, floor plate

Item number: SCETANHVP

Product description

Fixed height monitor stand & monitor wall mount for 42"-100" touch screen displays.

For applications that do not necessarily require height adjustment or where price is key, Conen Mounts offers a series of fixed height solutions. The monitor stands feature a sturdy aluminum center column that comes in different heights. Mounted atop the center column is the display mount which allows for cables to be stowed away neatly behind the display.

A 0.3" thick, solid steel plate secures to the center column. Designed for static, freestanding applications or to add stability to tv wall mount systems, secured to e.g. a stud wall. The floor plate features cut-outs/ handles for easy transportation. It comes powder coated in grey aluminum.

The unit comes flat-packed in 3 cartons and is courier-shippable.

Features

Entry model, fixed height wall mount
TV mount with integrated VESA pattern, max. 800 x 600
Mount allows for cables to be neatly stowed behind the display
Safe and stylish design: with the stylish aluminum center column supporting the weight of the display
Comes standard with the floor plate and 2 wall mount brackets for secure mounting to the wall

Product image Monitor stand and monitor wall mount, center of display 115 cm SCETANHVP

Item number	SCETANHVP
Vesa horizontal	300 mm - 800 mm
Vesa vertical	200 mm - 600 mm
Frame for all	42" - 100"
Center to floor distance	1178 mm	46.4"
Load capacity	250 kg	551.2 lbs
Width	890 mm	35"
Height	1498 mm	59"
Depth	530 mm	20.9"
Warranty	5 years limited warranty
Frame color	RAL 9005 deep black
Column color	Silver anodized
Base color	RAL 9006 white aluminum
Packages	Package dimensions WxHxD	Package weight
AF-SCETA-N	900 x 160 x 450 mm / 35.4 x 6.3 x 17.7"	13,6 kg / 30 lbs
CC-93W	1190 x 270 x 200 mm / 46.9 x 10.6 x 7.9"	15,3 kg / 33.7 lbs
PSTSCETA	750 x 20 x 600 mm / 29.5 x 0.8 x 23.6"	21,8 kg / 48.1 lbs
Total weight		50,7 kg / 111.8 lbs

Productimage 2 galvanized wall mounting brackets

Productimage Video conference camera top shelf LITE series for displays from 65 - 86 inch

Productimage 2 galvanized adjustable wall mounting brackets

Display mount for displays with max. VESA 800 x 600

This frame accommodates monitors with max. VESA 800 x 600. The sturdy construction consists of 2 mm powder coated steel. Power strips can be mounted on the frame and, thanks to the cable management, no cables hang down on the system.

Quick snap lock

With the new innovative quick snap locks the monitors can simply be hung in place on the monitor wall mount. This makes the assembly easy and fast. In addition, the monitor can be secured against theft with a standard pad lock.

8 mm strong floor plate

The 8 mm strong base plate allows the mounting of our monitor mounts on lightweight walls or a freestanding installation in the room. The weight of the monitor is transmitted through the column to the floor plate and thus to the floor, maximizing stability.

7 cm (2.76 inch) Z-brackets

By default, we supply wall mounting brackets with each display wall mount. This wall mounting set consists of two galvanized Z-shaped brackets, which allow a wall clearance of 7 cm (2.76 inch). Further wall mounting solutions are available as accessories.

Wall mounting kit

The system includes a wall mounting set consisting of: two galvanized Z-shaped brackets, which allow a wall clearance of 7 cm, Two sliding blocks incl. nut to attach the brackets to the column, four floor leveling feet and 3 cable clips.
