Motorized mobile XL flat screen tv & monitor cart, 50 cm of vertical travel

column black anodized, H-style base

Item number: SCEXLB

Product description

Motorized mobile tv cart stand with XL display mount.

Designed specifically for use with interactive touch screen monitors, this motorized mobile tv cart features an extra wide display mount. The mobile solution comes standard with the 2-tier column which offers 50 cm of height adjustment. Large handles on each side of the display are optionally available for the mobile stand to increase mobility and to help protect the display in transport.

Product ships flat-packed. Cartons are courier shippable.

Features

XL wide display mount with max. VESA 1200x600
Designed for use with LFDs and IFPDs
Easy mounting of display thanks to "pull & release" brackets
Display mount with integrated cable management
Actuator safely concealed in center column offering 50 cm of vertical travel
Wired remote is standard included

Product image Motorized mobile XL flat screen tv & monitor cart, 50 cm of vertical travel SCEXLB

Item number	SCEXLB
Vesa horizontal	400 mm - 1200 mm
Vesa vertical	200 mm - 600 mm
Frame for all	70" - 120"
Vertical travel	50 cm
Center to floor distance	1110 mm - 1610 mm	43.7" - 63.4"
Load capacity	136 kg	299.8 lbs
Width	1290 mm	50.8"
Height	1430 mm - 1930 mm	56.3" - 76"
Depth	720 mm	28.3"
Weight	63 kg	138.9 lbs
Warranty	5 years limited warranty
Frame color	RAL 9005 deep black
Column color	Black anodized
Base color	RAL 9005 deep black
Packages	Package dimensions WxHxD	Package weight
AFSCETAN12	1300 x 450 x 160 mm / 51.2 x 17.7 x 6.3"	17 kg / 37.5 lbs
CCE-50B	970 x 270 x 220 mm / 38.2 x 10.6 x 8.7"	19,5 kg / 43 lbs
MST-SCETAB	1140 x 150 x 780 mm / 44.9 x 5.9 x 30.7"	24,2 kg / 53.4 lbs
Total weight		60,7 kg / 133.9 lbs

Productimage Lockable mini PC bracket for frame mounting

Productimage Video conference camera top shelf LITE series for displays from 65 - 86 inch

Productimage Two large and sturdy handles including laptop shelf

Display mount XL for displays with max. VESA 1200 x 600

This XL frame accommodates monitors with max. VESA 1200 x 600. The sturdy construction consists of 2 mm powder coated steel. Power strips can be mounted on the frame and, thanks to the cable management, no cables hang down on the system.

Quick snap lock

With the new innovative quick snap locks the monitors can simply be hung in place on the monitor wall mount. This makes the assembly easy and fast. In addition, the monitor can be secured against theft with a standard pad lock.

Remote control of height adjustment

The electrically height-adjustable display & monitor stands come standard with a wired remote control. With two buttons, the display stand can gently be raised and lowered. Controlled movements protect the sensitive touch screen displays.

H-mobile stand

Our white H chassis has 4 smooth castors, two of which are lockable to fix the tv cart & mobile monitor stand in place. Due to the special H shape even wheelchair users can approach very close to the display.

Double-castor mobile stand

The smooth-running wheels on our chassis make it easy to move the mobile monitor stand and flat screen tv cart even with heavy displays. The castors have a diameter of 50 mm.
